Balanced Double Seat Control Valve, DN40-DN400, PN16-PN160

Balanced Double Seat Control Valve, DN40-DN400, PN16-PN160
Balanced Double Seat Control Valve, DN40-DN400, PN16-PN160

Key Specifications / Features

Model No.: CNCV-240426-BCV-01

Explore our balanced double seat control valves, designed for optimal performance in industrial settings. These cage-guided valves are available in sizes ranging from DN40 to DN400, with pressure ratings from PN16 to PN160. Crafted from carbon and alloy steel, they ensure durability and reliability in demanding environments. With ANSI B16.104 Class IV seat leakage classification, these valves provide tight shutoff and precise control. Choose from flange or welded ends to suit your specific application requirements.

Categories

Tags:

Request a quote

Detail Information


Product Name: Balanced Double Seat Control Valve
Trim: Double Seat Structure, Cage Guided Balanced Trim, Partial or Integrated Cage
Size Range: 1-1/2 Inch - 16 Inch, DN40-DN400
Pressure Rating: Class 150 LB - 900 LB, PN16-PN160, 1.6-16.0 Mpa
Body Material: ASTM A216 WCB, WCC, A217 WC6, WC9, ASTM A105
Seat Leakage: ANSI B16.104 CLASS IV (Standard, Metal Seat)
Connection: Flange, Welding
Rangeability: 50:1
Temperature Range: -196℃ to 538℃
Flow Characteristic: Equal Percentage, Linear
