Product Name: Explosion Proof
Electric Actuator
Electric Machine: Squirrel Cage Asynchronous Motor
Motor Power: AC 110/220V Single Phase, AC 380/440V 3 Phase, 50/60Hz, ±10%
Control Signal: Input and Output 4-20mA
Shell: IP67
Stroke: 90° (±10°) (180°, 270° Optional)
Self Locking Device: Worm Gear and Worm Mechanism provide Self-locking
Ambient Temperature: -20°C to +70°C
Explosion Proof Electric Actuators
Certification: Designed for Class I Div 1 conditions, these actuators are certified to operate safely in environments with hazardous gases and dusts.
Flameproof Design: Equipped with flameproof enclosures and conduit seals to prevent the ignition of flammable substances by containing sparks and heat.
Robust Construction: The metal housing is engineered to withstand high pressures during potential blast events, ensuring durability and safety.
Dual Seal Protection: Power shaft dual seals isolate the actuator's interior from the external atmosphere, providing an additional layer of safety against ignition.
Temperature Range: Suitable for a wide range of temperatures, these actuators prevent ignition risks in environments with flammable gases, vapors, or fibers.
PLC-based Control: Featuring a programmable logic controller (PLC), these actuators allow for customized programming tailored to specific applications, enhancing operational flexibility.
Global Certifications: Holding UL, ATEX, IECEx, and other certifications, these actuators are approved for use in oil/gas, chemical/pharma, and other industries where combustible materials are handled.
