PTFE Lined Butterfly Control Valve, WCB, DN50-DN600, PN6-PN16

PTFE Lined Butterfly Control Valve, WCB, DN50-DN600, PN6-PN16
PTFE Lined Butterfly Control Valve, WCB, DN50-DN600, PN6-PN16

Key Specifications / Features

Model No.: CNCV-240426-BFCV-01

Discover our PTFE lined butterfly control valves, crafted from ASTM A216 WCB, available in sizes ranging from 2 to 24 inches (DN50-DN600). With pressure ratings from Class 125 to 150 LB (PN6-PN16), these valves provide exceptional corrosion resistance and reliable performance. Engineered to minimize seat leakage to ANSI B16.104 Class VI standards, they feature flange and wafer ends, ensuring versatile installation options for various industrial applications.

Categories

Tags:

Request a quote

Detail Information


Product Name: PTFE Lined Butterfly Control Valve
Trim: Central Lining
Size Range: 2 Inch - 24 Inch, DN50-DN600
Pressure Rating: Class 125 LB - 150 LB, PN6-PN16, 0.6-1.6 Mpa
Body Material: ASTM A216 WCB
Seat Material: PTFE, F46, PFA
Seat Leakage: ANSI B16.104 CLASS VI
Connection: Flange, Wafer
Rangeability: 30:1
Temperature Range: -45℃ to 250℃
Flow Characteristic: Approximate Equal Percentage
