Self-operated Control Valve, ASTM A216 WCB, 2 Inch, 150 LB

Name: Self-operated Control Valve, ASTM A216 WCB, 2 Inch, 150 LB
SKU: cncv-240625-ucv-01
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model No.: CNCV-240625-UCV-01

Our self-operated pressure control valve manufacturer offers a reliable solution featuring a single-seated design made from ASTM A216 WCB carbon steel. This valve is designed for optimal performance, with a 2-inch diameter and a Class 150 LB pressure rating. It is equipped with a multi-spring diaphragm pneumatic actuator, ensuring precise and responsive pressure control without external power requirements. Ideal for a wide range of industrial applications, this valve combines robust construction with efficient operation to maintain consistent pressure levels with minimal intervention.

Detail Information

Product Name: Self-operated Control Valve
Key Features: Single Seated, Pressure Control
Body Material: ASTM A216 WCB
Size: 2 Inch, DN50
Pressure: Class 150 LB, PN16
End Connection: Flanged
Actuation: Multi-Spring Diaphragm Pneumatic Actuator

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Size Range: 3/4-12 Inch, DN20-DN300
Pressure Rating: PN16-PN100, Class 150-600 LB
Working Temperature: -9°C to 350°C
End Connections: Flanged, Welded
Flow Characteristics: Quick Open
Seat Leakage: ANSI B16.104 Class IV (Hard Seal), Class VI (Soft Seal)
Actuator Options: Multi-Spring Diaphragm Pneumatic Actuator
Air Supply Pressure: 0.14, 0.16, 0.28, 0.4 MPa
