Product Name: Stainless Steel 316L Globe Control Valve
Material: Stainless Steel SS 316L
Size: 5 Inch, DN125
Pressure: Class 150 LB, PN10
End Connection: Flanged
Actuator: Pneumatic Linear Actuator
Leakage Class: ANSI/FCI 70-2
Product Range
Body Material: Carbon Steel, Stainless Steel
Size Range: 1-1/2-18 Inch, DN40-DN450
Pressure Rating: Class 150-600 LB, PN6-PN100
End Connection: Flanged
Flow Characteristic: Linear, Equal Percentage, Quick Open
Working Temperature: -40°C to 450°C
Ambient Temperature: -20°C to 90°C
Actuator Options: Pneumatic Actuators
Air Supply: 2.5 Bars to 8 Bars, Max 10 Bars
Function: On-off, Quick Opening and Closing, Emergency Shut-down
Stainless Steel 316L Globe Control Valve-Features
1. Simplicity in Design: The cylinder boasts a straightforward structure that facilitates easy manufacturing and maintenance processes.
2. Safe and Eco-Friendly Medium: Utilizes compressed air or nitrogen as the operating medium, ensuring safety and environmental sustainability.
3. Remote Control Capability: The cylinder is equipped to control valves remotely through the intake chamber or lower chamber inlet mechanisms.
4. Efficient Operation: Characterized by a short working stroke, leading to swift opening and closing actions.
5. Advanced Sealing Mechanism: The sealing surface of the valve and its seat employs a conical seal design, which requires minimal closing force, is resistant to erosion, and ensures a dependable seal.
6. Replaceable Valve Seat: The valve seat is designed to be replaceable, allowing for flexible combination and matching with the sealing surface material of the closing member. This adaptability meets diverse working condition requirements and enhances the service life of the equipment.
